Product Features：
Intelligent control system
◆ Five groups of programs with humanized design.
◆ Program group shortcut key, can store 99 groups of program , convenient to call at any time.
◆ Automatic electronic door lock.
◆ With instantaneous and continuous centrifugation functions.
Excellent kernel performance
◆ HD large LCD touch display and the parameters can be revised during operation without shutdown.
◆ Microcomputer control ,AC frequency conversion brush-less motor with fast speed and stable operation.
◆ 10 gears acceleration /deceleration with linear drive.
◆ Two modes can be set: start timing/arrival revolution timing.
Careful and safe
◆ With rotor automatic identification system .
◆ Over speed,over heat,unbalance protections with auto lid lock.
◆ Steel Structure,centrifuge chamber made of stainless steel with Environmentally friendly anti-corrosion coating treatment.
Intimate detail design
◆ Special noise reduction system.
◆ An intimate tool rack is provided for accompanying tools to guard the instrument at all times.
◆ With an operation SOP guide map, which makes it easier and more standard for laboratory workers.
◆ Equipped with rotor lid that can be quickly locked for easy use.
Technical Parameter：
Max Speed | 5500rpm | Power | 1000W |
Max RCF | 5071×g | Noise Level | ≤ 62dB（A） |
Max Capacity | 4×750ml | Size | 460×580×400 (mm) |
Timer | 1s～99h59min59s | Net Weight | 62kg |
Revolutions/min | ±10r/min | Rotor automatic recognition | Yes |
Voltage | AC 220±22V 50Hz 10A or custom | / | / |
Rotor parameters：
Rotor Name | Rotor NO. | NO. | Capacity | Max Speed（r/min) | Max RCF(×g) |
Angle rotor（W) | 1 | 1 | 40×15ml | 5500rpm | 5071×g |
Angle rotor（W) | 2 | 2 | 6×50ml | 5500rpm | 3645×g |
Swing-out rotor | 3 | 3 | 120×2~7ml（Blood collection tube） | 4000rpm | 3309×g |
4 | 4×750ml(Round bucket) | 4000rpm | 3309×g |
5 | 4×750ml(Round bucket)/ （with biosafety lid） | 4000rpm | 3309×g |
6 | 4×750ml Square bucket(used with adapters) | 4000rpm | 3309×g |
Swing-out rotor | 4 | 7 | Auto uncap 104×2-7ml(blood collection tube) | 4000rpm | 3184×g |
8 | 4×500ml(Round bucket) | 4000rpm | 3184×g |
9 | 4×500ml(Round bucket) （with biosafetey lid） | 4000rpm | 3184×g |
10 | 4×500ml Square bucket (used with adapters) | 4000rpm | 3184×g |
Swing-out rotor | 5 | 11 | Auto uncap 64×2-7ml(blood collection tube) | 4000rpm | 3040×g |
12 | 4×250ml(Round bucket) | 4000rpm | 3040×g |
13 | 4×250ml(Round bucket)/ （with biosafety lid） | 4000rpm | 3040×g |
14 | 4×250ml Square bucket (used with adapters) | 4000rpm | 3040×g |
15 | 4×250ml Sharp bucket（Corning tube） | 4000rpm | 3040×g |
16 | 6×250ml(Round bucket) | 4000rpm | 3040×g |
Swing-out rotor | 6 | 17 | Multifunctional three-in-one rotor 4×750ml match with below(Bucket/Basket) to use |
Hanging bucket | 6 | 18 | 750ml round bucket with bio-safety cover include adapters： 4×14×15ml(conical bottom) 4×7×50ml(conical bottom) | 4000rpm | 3425×g |
Hanging basket | 19 | Micro-plate 4×2×96 hole | 4000rpm | 3425×g |
Hanging bucket | 20 | Auto uncap 120×2-7ml (blood collection tube) | 4000rpm | 3425×g |
Hanging bucket | 21 | Specialized for 500ml bloodbag (include the bloodbag adapter) | 4000rpm | 3425×g |
Swing-out rotor | 7 | 22 | Micro-plate 2×2×96 hole | 4000rpm | 2057×g |
* All products can be customized, designed and produced according to customer requirements.
