Key Features:
1. Small size; great space saver for the lab.
2. Steel structure, centrifuge chamber made of stainless steel.
3. maintenance free brushless DC motor drive to enable stable and quiet operation.
4. Able to change parameters anytime during operation without the need to stop the machine
5. automatic calculation and simultaneous display of RCF/RPM.
6. 10 types of accelerating/decelerating control, 40 groups of programming space, user able to program and call program freely.
7. With electronic door lock, enhanced safety.
8. This model is widely used in laboratories in hospitals and institutions due to its super high performance cost ratio and reliable quality.
Technical Parameter：
Model | TD4X | |||
Max RPM (rpm) | 4000rpm | Noise Level | ≤ 65dB（A） | |
Max RCF | 2250×g | Chamber diameter | φ280mm | |
Max Capacity | 18×10ml | Outer Dimensions | 385×320×270mm | |
Timer | 1min～99min | Packing Dimensions | 460×390×330 mm | |
Revolutions/min | ±20r/min | Net weight | 15kg | |
Voltage | AC 220V±22V，50/60Hz，10A | Gross weight | 17kg | |
Power | 100W | / | / | |
Rotor | No. | Compacity | RPM/RCF | |
Angle Rotor | 1 | 12×10ml | 4000rpm/2250×g | |
2 | 18×10ml | 4000rpm/2250×g | ||
