Key Features:
◎Medium footprint, good compatibility, suitable for medium and small sized multi-functional experiments
◎controlled by computer, AC frequency variable motor drive
◎Multi-color LCD display, user-friendly, clearer and more direct display. .
◎Auto-calculation and configure centrifugal force and RCF value.
◎Adopted special shock absorber with auto balance function.
◎With electronic door lock, enhanced safety
◎Multiple types of stainless steel tube stands, easy to change
Overall Specifications：
Model | L3-6K | |||
maximum RPM | 6500rpm | centrifuge chamber diameter | φ380mm | |
maximum RCF | 5190×g | noise level | < 65dB（A） | |
maximum capacity | 4×250 ml | dimensions (length x width x height) | 525×430×360mm | |
timing range | 1min～99min | packaging dimensions (length x width x height) | 625×530×460mm | |
RPM accuracy | ±20r/min | Net Weight | 40kg | |
power supply | AC 220±22V 50Hz 10A | Gross Weight | 48kg | |
total power | 500W | \// | // | |
Rotor Type | Number | Rotor Capacity | RPM/RCF | |
angle rotor（bowl shaped） | 1 | 6×50ml | 6500rpm/5190×g | |
Horizontal Rotor
| 2 | 4×50/100ml | 5000rpm/4390×g | |
3 | 8×50/100ml | 4200rpm/3100×g | ||
4 | 48×5/7ml | 4200rpm/3100×g | ||
5 | 64×5/7ml | 4200rpm/3100×g | ||
6 | 72×5/7ml | 4200rpm/3100×g | ||
7 | 16×10/15ml | 4200rpm/3100×g | ||
8 | 24×10/15ml | 4200rpm/3100×g | ||
9 | 32×10/15ml | 4200rpm/3100×g | ||
10 | 4×250ml | 4200rpm/3850×g | ||
Enzyme labelled plate rotor | 11 | 2×2×96 wells | 4200rpm/2530×g | |
12 | 2×2×48 wells | 4200rpm/1900×g | ||
