Key Features:
◎Controlled by computers, AC frequency variable motor drive, able to operate stably and quietly
◎Multi-color LED displaying parameters including RPM, eccentricity, temperature and time，Able to change parameters anytime during operation without the need to stop the machine
◎Able to configure centrifugal force, RCF and interchangeable, able to observe anytime
◎Equipped with short spin press button
◎10 types of acceleration and deceleration control, the 9th control able to achieve free stopping time longer than 540s, able to satisfy the requirement of some special samples.
◎Second display for countdown less than one minute
◎Adopted electronic door lock, inner chamber protected by steel materials
◎Imported high efficiency environmental friendly refrigerating system, able to maintain temperature under -4℃ during maximum RPM
◎L3-5KR is equipped with multiple types of rotor and adaptors, applicable to radioactive immunology, clinical medicine, biochemistry, pharmaceutics, isolation and purification of blood samples.
Overall Specifications：
Model | L3-5KR | |||
maximum RPM | 5000rpm | power supply | AC 220±22V 50Hz 10A | |
maximum RCF | 4390×g | total power | 750W | |
maximum capacity | 4×250ml | noise level | < 65dB（A） | |
timing range | 1min～99min | centrifuge chamber diameter | φ380mm | |
temperature range | -20℃～40℃ | dimensions (length x width x height) | 580×660×365mm | |
temperature accuracy | ±2.0℃ | packaging dimensions (length x width x height) | 680×760×465mm | |
RPM accuracy | ±20r/min | Net Weight | 70kg | |
/ | / | Gross Weight | 85kg | |
Rotor type | Number | Rotor Capacity | RPM/RCF | |
Horizontal Rotor
| 1 | 4×50/100ml | 5000rpm/4390×g | |
2 | 8×50/100ml | 4000rpm/2810×g | ||
3 | 48×5/7ml | 4000rpm/2810×g | ||
4 | 64×5/7ml | 4000rpm/2810×g | ||
5 | 72×5/7ml | 4000rpm/2810×g | ||
6 | 16×10/15ml | 4000rpm/2810×g | ||
7 | 24×10/15ml | 4000rpm/2810×g | ||
8 | 32×10/15ml | 4000rpm/2810×g | ||
9 | 4×250ml | 4000rpm/3500×g | ||
Enzyme labelled plate rotor | 10 | 2×2×96 wells | 4000rpm/2300×g | |
11 | 2×2×48 wells | 4000rpm/1700×g | ||
Key Features:
◎Controlled by computers, AC frequency variable motor drive, able to operate stably and quietly
◎Multi-color LED displaying parameters including RPM, eccentricity, temperature and time，Able to change parameters anytime during operation without the need to stop the machine
◎Able to configure centrifugal force, RCF and interchangeable, able to observe anytime
◎Equipped with short spin press button
◎10 types of acceleration and deceleration control, the 9th control able to achieve free stopping time longer than 540s, able to satisfy the requirement of some special samples.
◎Second display for countdown less than one minute
◎Adopted electronic door lock, inner chamber protected by steel materials
◎Imported high efficiency environmental friendly refrigerating system, able to maintain temperature under -4℃ during maximum RPM
◎L3-5KR is equipped with multiple types of rotor and adaptors, applicable to radioactive immunology, clinical medicine, biochemistry, pharmaceutics, isolation and purification of blood samples.
Overall Specifications：
Model | L3-5KR | |||
maximum RPM | 5000rpm | power supply | AC 220±22V 50Hz 10A | |
maximum RCF | 4390×g | total power | 750W | |
maximum capacity | 4×250ml | noise level | < 65dB（A） | |
timing range | 1min～99min | centrifuge chamber diameter | φ380mm | |
temperature range | -20℃～40℃ | dimensions (length x width x height) | 580×660×365mm | |
temperature accuracy | ±2.0℃ | packaging dimensions (length x width x height) | 680×760×465mm | |
RPM accuracy | ±20r/min | Net Weight | 70kg | |
/ | / | Gross Weight | 85kg | |
Rotor type | Number | Rotor Capacity | RPM/RCF | |
Horizontal Rotor
| 1 | 4×50/100ml | 5000rpm/4390×g | |
2 | 8×50/100ml | 4000rpm/2810×g | ||
3 | 48×5/7ml | 4000rpm/2810×g | ||
4 | 64×5/7ml | 4000rpm/2810×g | ||
5 | 72×5/7ml | 4000rpm/2810×g | ||
6 | 16×10/15ml | 4000rpm/2810×g | ||
7 | 24×10/15ml | 4000rpm/2810×g | ||
8 | 32×10/15ml | 4000rpm/2810×g | ||
9 | 4×250ml | 4000rpm/3500×g | ||
Enzyme labelled plate rotor | 10 | 2×2×96 wells | 4000rpm/2300×g | |
11 | 2×2×48 wells | 4000rpm/1700×g | ||
