H2-16K-II
Key Features：
1. small footprint; great space saver for the lab
2. Steel structure, centrifuge chamber made of stainless steel.
3. AC frequency variable motor drive, able to operate stably and quietly。
4. 10 gear for accelerating and deceleration control, The free stopping time of the ninth gears can reach more than 540S, which meets the requirements of the special separation products.
5. Multi-color LED display, user-friendly, clearer and more direct display.
6. Able to adjust timing and RPM during operation anytime, as well as to check centrifugal force without stopping the machine.
7. Automatic calculation and display RCF value, RPM and centrifugal force at the same time.
8. With electronic door lock, enhanced safety.
9. Set short time special centrifugal inching key.
Applications:
1. Ethanol precipitated nucleic acid PCR experiment, phenol chloroform extraction from virus and bacteria samples.
2. Cell homogenization followed by fractioning centrifuge.
3. PCR product purification.
Technical Parameter：
Model | H2-16K-II | |||
Max RPM (rpm) | 16500rpm | Noise Level | ≤ 65dB（A） | |
Max RCF | 18360×g | Chamber diameter | φ250mm | |
Max Capacity | 6×50ml | Outer Dimensions | 400×300×330(mm) | |
Timer | 1min～99min | Outer packing Dimensions | 410×310×360(mm) | |
Revolutions/min | ±20r/min | Net weight | 23kg | |
Voltage | AC 220±22V 50/60Hz 5A | Gross weight | 30kg | |
Power | 420W | / | / | |
Rotor | No | Capacity | RPM/RCF | |
Angle Rotor | 1 | 12/16×1.5/2.2ml | 16500rpm/18360×g | |
2 | 12×10ml | 12000rpm/14800×g | ||
3 | 6×50ml/round bottom | 11000rpm/ 12840×g | ||
