◆ The machine has an operation SOP guide map, which is more convenient for laboratory workers to use .
The front of the fuselage is designed with an operation SOP guide map, which makes it easier and more standard for laboratory personnel to use the instrument.
◆ Equipped with rotor lid that can be quickly locked.
◆ Ergonomic, low opening height, close the centrifuge lid with one time press.
◆ Special noise reduction system .
Technical Parameter：
Model | GR30C |
Max Speed | 30000rpm | Voltage | AC 220±22V 50Hz 15A or custom |
Max RCF | 65100×g | Power | 1500W |
Max Capacity | 6×100ml | Noise Level | ≤ 62dB（A） |
Timer | 1s～99h59min59s | Size | 730×660×400mm |
Revolutions/min | ±10r/min | Net Weight | 120kg |
Temp Range | -20℃～40℃ | Rotor automatic recognition | Yes |
Temp Accuracy | ±1.0℃ | / | / |
Rotor parameters：
Rotor Name | Rotor NO. | NO. | Capacity | Max Speed（r/min) | Max RCF(×g) |
Angle rotor | 1 | 1 | 12×1.5/2.0ml(titanium alloy) | 30000rpm | 65100×g |
2 | 2 | 10×5ml(titanium alloy) | 25000rpm | 44978×g |
3 | 3 | 24×1.5/2.0ml （D） | 20000rpm | 38427×g |
4 | 4 | 12×10ml | 19000rpm | 32529×g |
5 | 5 | 48×1.5/2.0ml | 19000rpm | 39149×g |
6 | 6 | 6×50ml(round bottom) | 16500rpm | 27622×g |
7 | 7 | 8×50ml(round bottom) | 16000rpm | 28549×g |
8 | 8 | 6×50ml(conical/round bottom) | 15000rpm | 25375×g |
9 | 9 | 12×15ml | 14000rpm | 22241×g |
10 | 10 | 6×100ml | 13500rpm | 22209×g |
